EPD320M-IE

(32-INCH / MONOCHROME)

Introducing the EPD320M-IE 32″ Electronic Paper Display from TeamUC. The EPD320M-IE is a high-resolution display with amazing clarity that comes in monochrome. The unit requires minimal power making it versatile for applications across various industries/markets. Like looking at actual paper, the visual output is soothing yet comforting to the eye, eliminating the possibility of eye strain from screen exposure.



The EPD320M-IE is perfectly suited for implementation under various environments such as Menu/Message boards in retail, Directory/Info boards in Healthcare/Medical, Real-time route updates at bus stops, and also for special types of writing such as Calligraphy. You just can’t go wrong with the EPD320M-IE from TeamUC.

FEATURES:

  • Low power
  • Easy installation
  • Remotely updateable
  • Indoor and outdoor applications
  • Print-like appearance
  • Non-glare background
  • High contrast

APPLICATIONS

SPECIFICATIONS

CONFIGURATIONS

PACKAGING

RELATED ITEMS

APPLICATIONS

SPECIFICATIONS

HARDWARE DESCRIPTION
 Size  32″
Screen Technology E Ink Monochrome
Resolution 2560 x 1440
Color 16 Grey Level
Contrast Ratio 13:1
Flash Size eMMC 8G
DDR DDR2 512MB
G-Sensor For Portrait Mode & Landscape Mode
Battery (Optional) Detachable rechargeable lithium battery 10,200mAh
HARDWARE DESCRIPTION
Button Power On/Off/Reset
Connectivity Wi-Fi, BT4.1, Ethernet
OS Android 4.4 or up
Type DC (12V/4A)
Bezel Width 5.7mm/5.7mm/5.7mm/15mm (Left/Right/Top/Bottom)
Wall Mount VESA Mount 200 mm x 200 mm
External Dimensions 703.6 x 410.5 x 8.8 mm (with 2mm tempered glass)
Weight 6.5 Kg/14 Lb
Operating Temperature 0°C~50°C

CONFIGURATIONS

MODEL DESCRIPTION
 EPD320M-IE     32” Indoor Monochrome EPD complete unit enclosure / 2mm tempered glass w/o front light, Wifi/BT/Ethernet/LTE interface

INSIDE THE BOX



   EPD320M-IE
   Power Cable
   Power Adapter

DIMENSIONS



   20″(W) x 34″(L) x 4″(H)
   Weight: 19 lbs.
